Best Quality Flame Retardant & Fire Resistance FRP Lab Fume Hood Or Bench Top Fume Hood Manufacturers
stars, based on 0reviews
Products Description
(Machine Press) Flame Retardant FRP Fume Hood
Special Functions:
Machine (pressure) FRP fume hood (flame retardant)
1.1. Machine (pressure) FRP fume hood (flame retardant type) conforms to the "general technical conditions for laboratory
furniture" (GB24820-2009) standard.
▲1.2 Flame retardant FRP fume hood upper and lower box machine molding: are made of high polymer materials through machine
equipment high temperature hot pressing curing reverse mold, with acid resistance, corrosion resistance, high temperature
resistance, flame retardant, scratch resistance, long service life, environmental protection and other characteristics.
1.3. There is no additional layer inside the molded product, and the material inside and outside is the same.The main panel of
flame retardant FRP fume hood is designed and processed with bright leather grain, beautiful and generous.
1.4.[upper box] all use flame retardant FRP open die overall pressing die, one molding.And is equipped with the function of
condensate connection trough.Good anti-corrosion performance, beautiful appearance, no leakage.
1.5.[lower box] all use flame retardant glass steel material.
1.6.[Top of upper box] The top cover is removable. The cover is moisture-proof and dust-proof, solid, beautiful and environmental
friendly
1.7. The flame-retardant FRP fume hood roof and lampshade are all made of flame-retardant and anticorrosive materials, which are
cured by machine and equipment at high temperature by hot pressing and reverse-molding. It is equipped with a wind direction guide
layer and a condensate connection groove function to prevent liquid backflow.The three - proof lamp is installed on the top cover
of the fume hood to prevent the contact with the gas inside the fume hood and the room.
1.8. Flame retardant FRP ventilation cabinet guide board: unique guide board design, equipped with the function of wind speed
adjustment, must avoid the dead Angle of exhaust air, is also made of polymer composite material after machine equipment high
temperature hot pressing curing inverted mold.There is an automatic collection device for condensate water in the diversion layer,
and the condensate water can be discharged safely according to the specified requirements.
1.9. There are safety access doors on both sides of the inner wall of flame retardant FRP fume hood to facilitate the installation
and maintenance of water and air.The material of the inspection door is the same as that of the cabinet body, which is made of FRP
flame retardant and anti-corrosion material by machine pressing once.
1.10. Window: monolithic vertical window with up and down door structure, placed between the operating space and the operator to
protect the operator's safety, and the window can be stopped at any activity point.
(1) window glass: 5.0mm tempered glass, clear vision, no obstruction.
(2) window handle: the use of anticorrosive PP profile, handle upper and lower are arc shape, with the effect of flow guide, to
avoid the generation of eddy current.
(3) window frame: the use of anticorrosive PP profile, four sides of embedded clamping combined design, to ensure safety and
durability.
(4) Transmission mechanism: the synchronous belt, synchronous shaft combined transmission structure.Slide freely, can make the
glass door arbitrary stay.
1.11. Flame retardant FRP fume hood door plate: using flame retardant anti-corrosion FRP steel (without any sandwich inside),
interior and exterior door combined design, can root need to use different colors of interior and exterior doors to match, so that
the whole product has more beautiful.
1.12. Flame retardant FRP fume hood door handle: the mold is formed once, the structure is tight and not easy to fall off.
1.13. The upper and lower boxes of flame retardant FRP fume hood can be disassembled and assembled as a whole, and the nuts are
embedded in the glass plate. The whole product has the characteristics of easy disassembly, easy relocation and freight saving.
1.14.[operating table] using 20+5mm thick solid core firing laboratory special ceramic table, the whole table is one high
temperature firing molding, operating surface part of the whole concave 5mm warped edge, the total thickness of 25mm, to prevent
harmful liquid spiltration.Table resistant to strong corrosion, high temperature resistance, wear resistance, easy to clean, never
deformation discoloration, beautiful, safe and environmental protection, free from maintenance.Glaze color: black, blue, gray
1.15. The wind speed of the table of flame retardant FRP fume hood is 0.3-0.8m /S, and the voltage is 220V or 380V.Noise: ≤60dB.
1.16. Accessories: the electronic control adopts Chinese and English LCD ultra-thin display screen mounted on the column of the
fume hood, and the plug-in connection design is convenient for operation and maintenance. With voltage regulator adapter, it has
good anti-corrosion performance.
1.17. Electricity: 2 power sockets, including 4 220V/10A multifunctional sockets.
1.18. Flame retardant FRP fume hood liquid resistance: liquid resistance to meet 10% sodium carbonate solution, 30% acetic acid,
5% hydrochloric acid, 10% sodium hydroxide solution more than 20 hours without obvious change,
▲1.19. Flame retardant level reached V-0 level, meet the national (GB/T2408-2008) inspection standards;
1.20. Formaldehyde emission ≤0.1mg/L, meeting the national inspection standard (GB/T 17657-20134.59);
1.21. Oxygen index ≥31.8%, meeting the national inspection standard (GB/T 2406.2-2009);
1.22. Surface resistivity reaches 9.31*10¹³Ω.
1.1. Machine (pressure) FRP fume hood (flame retardant type) conforms to the "general technical conditions for laboratory
furniture" (GB24820-2009) standard.
▲1.2 Flame retardant FRP fume hood upper and lower box machine molding: are made of high polymer materials through machine
equipment high temperature hot pressing curing reverse mold, with acid resistance, corrosion resistance, high temperature
resistance, flame retardant, scratch resistance, long service life, environmental protection and other characteristics.
1.3. There is no additional layer inside the molded product, and the material inside and outside is the same.The main panel of
flame retardant FRP fume hood is designed and processed with bright leather grain, beautiful and generous.
1.4.[upper box] all use flame retardant FRP open die overall pressing die, one molding.And is equipped with the function of
condensate connection trough.Good anti-corrosion performance, beautiful appearance, no leakage.
1.5.[lower box] all use flame retardant glass steel material.
1.6.[Top of upper box] The top cover is removable. The cover is moisture-proof and dust-proof, solid, beautiful and environmental
friendly
1.7. The flame-retardant FRP fume hood roof and lampshade are all made of flame-retardant and anticorrosive materials, which are
cured by machine and equipment at high temperature by hot pressing and reverse-molding. It is equipped with a wind direction guide
layer and a condensate connection groove function to prevent liquid backflow.The three - proof lamp is installed on the top cover
of the fume hood to prevent the contact with the gas inside the fume hood and the room.
1.8. Flame retardant FRP ventilation cabinet guide board: unique guide board design, equipped with the function of wind speed
adjustment, must avoid the dead Angle of exhaust air, is also made of polymer composite material after machine equipment high
temperature hot pressing curing inverted mold.There is an automatic collection device for condensate water in the diversion layer,
and the condensate water can be discharged safely according to the specified requirements.
1.9. There are safety access doors on both sides of the inner wall of flame retardant FRP fume hood to facilitate the installation
and maintenance of water and air.The material of the inspection door is the same as that of the cabinet body, which is made of FRP
flame retardant and anti-corrosion material by machine pressing once.
1.10. Window: monolithic vertical window with up and down door structure, placed between the operating space and the operator to
protect the operator's safety, and the window can be stopped at any activity point.
(1) window glass: 5.0mm tempered glass, clear vision, no obstruction.
(2) window handle: the use of anticorrosive PP profile, handle upper and lower are arc shape, with the effect of flow guide, to
avoid the generation of eddy current.
(3) window frame: the use of anticorrosive PP profile, four sides of embedded clamping combined design, to ensure safety and
durability.
(4) Transmission mechanism: the synchronous belt, synchronous shaft combined transmission structure.Slide freely, can make the
glass door arbitrary stay.
1.11. Flame retardant FRP fume hood door plate: using flame retardant anti-corrosion FRP steel (without any sandwich inside),
interior and exterior door combined design, can root need to use different colors of interior and exterior doors to match, so that
the whole product has more beautiful.
1.12. Flame retardant FRP fume hood door handle: the mold is formed once, the structure is tight and not easy to fall off.
1.13. The upper and lower boxes of flame retardant FRP fume hood can be disassembled and assembled as a whole, and the nuts are
embedded in the glass plate. The whole product has the characteristics of easy disassembly, easy relocation and freight saving.
1.14.[operating table] using 20+5mm thick solid core firing laboratory special ceramic table, the whole table is one high
temperature firing molding, operating surface part of the whole concave 5mm warped edge, the total thickness of 25mm, to prevent
harmful liquid spiltration.Table resistant to strong corrosion, high temperature resistance, wear resistance, easy to clean, never
deformation discoloration, beautiful, safe and environmental protection, free from maintenance.Glaze color: black, blue, gray
1.15. The wind speed of the table of flame retardant FRP fume hood is 0.3-0.8m /S, and the voltage is 220V or 380V.Noise: ≤60dB.
1.16. Accessories: the electronic control adopts Chinese and English LCD ultra-thin display screen mounted on the column of the
fume hood, and the plug-in connection design is convenient for operation and maintenance. With voltage regulator adapter, it has
good anti-corrosion performance.
1.17. Electricity: 2 power sockets, including 4 220V/10A multifunctional sockets.
1.18. Flame retardant FRP fume hood liquid resistance: liquid resistance to meet 10% sodium carbonate solution, 30% acetic acid,
5% hydrochloric acid, 10% sodium hydroxide solution more than 20 hours without obvious change,
▲1.19. Flame retardant level reached V-0 level, meet the national (GB/T2408-2008) inspection standards;
1.20. Formaldehyde emission ≤0.1mg/L, meeting the national inspection standard (GB/T 17657-20134.59);
1.21. Oxygen index ≥31.8%, meeting the national inspection standard (GB/T 2406.2-2009);
1.22. Surface resistivity reaches 9.31*10¹³Ω.
Features
1.The upper and lower boxes of the fume hood are made of imported polymer composite sheet materials through 4000 tons of machinery and equipment, high temperature, heat, and solidification.
2.It has the characteristics of acid resistance, corrosion resistance, high temperature resistance, flame retardant, scratch resistance, long service life, and environmental protection.
3.Unique deflector design, equipped with the function of adjusting the wind speed, will avoid the dead angle of exhaust.
4.There is an automatic condensate collection device in the diversion layer, and the condensate can be safely discharged according to the specified requirements.
5.The fume hood is equipped with internal and external air supply functions. If the exhaust air cannot meet the needs, the air supply function is automatically realized.
6.There are safety inspection doors on both sides of the inner wall of the fume hood to facilitate the installation and inspection of water and air.
7.The upper and lower boxes of the fume hood can be disassembled as a whole, and the nuts are embedded in the glass steel plate. The whole product has the characteristics of easy disassembly, easy removal, and freight saving.
External Size(W*D*H) | 1245*800*2300mm | 1500*800*2300mm | 1800*800*2300mm | ||
Internal Size(W*D*H) | 950*650*1100mm | 1250*650*1100mm | 1550*650*1100mm | ||
Exhaust Air Volume | 1200~1800m3/h | 1500~2000m3/h | 1800~3000m3/h | ||
Work Surface Height | 850mm | ||||
Air Velocity | 0.3~0.8m/s | ||||
Noise | ≤60Db(A) | ||||
Sash | 5mm thickness tempered glass | ||||
Worktop | Phenolic resin / Epoxy resin / Ceramic / Trespa / SUS / PP | ||||
Lighting | Full cover type LED lamp with 220V * 20W * 2 | ||||
Operation Panel | Switch of Lighting,ON/OFF,Electric socket and Blower | ||||
Blower | Small and indoor type , Material: PP , Power: 300KW | ||||
Sink | PP sink, Epoxy resin sink | ||||
Electric Socket | Multi-functional type,220V/10A | ||||
Working Door Opening | 800mm~1000mm | ||||
Option | Water supply, gas supply |






Company Profile

Our Advantages

Certifications

Packing&Shipping

FAQ

- General Use:
- Commercial Furniture
- Type:
- Laboratory Furniture
- Mail packing:
- N
- Application:
- Hospital, School, Laboratory Furniture
- Design Style:
- Modern
- Material:
- 6mm thickness FRP
- Place of Origin:
- Guangdong, China
- Brand Name:
- SUCLAB
- Model Number:
- HZJ-FFH01
- Product name:
- FRP Fume Hood
- Worktop:
- FRP ,Phenolic or Epoxy resin board
- Structure:
- Floor Mounted Fume Hood or Bench Top Fume Hood
- Surface Treatment:
- Static Powder Coating(Rough or Smooth)
- Color:
- Gray white,blue
- Function:
- Fame retardant , Fire Resistance
- Size:
- 1245/1500/1800*800/900*2300
